UC802P is an entry model of business class IP Phone, optimized for executive use with a LCD that gives an easy access to many powerful features.
UC802P comes with 2 SIP account keys and 5 programmable keys that could be configured as IPBX features (BLF, SCA, Intercom, Call Pickup, Call Park and many other).
Easy deployment on professional Lan with 2 Ethernet ports, power over ethernet (PoE) and auto-provision features.
High Definition voice sound (G.722), HD hands-free speakerphone and HD headset control ensure a comfortable everyday use.
The UC802P IP phone is complying with a wide range of IP platforms (IPBX, Centrex SIP, etc.).
128x40px graphic LCD
2 Ethernet ports 10/100MB
2 SIP account keys, 5 programmable keys (BLA/BLF), 4 navigation keys
Handset : 1 RJ9(4P4C)
Headset : 1 RJ9(4P4C)
Power adapter (included): 5V/1.2A
Power over Ethernet(PoE) : IEEE 802.3af
Desk or wall mountable
Dimensions: 205x205x70mm - Weight: 0.71kg
SIPv2, SDP (RFC2327), RTP (RFC1889,1890), RTCP, RFC2833 X-NSE Tone Events for SIP/RTP, AVT Tone Events for SIP/RTP
HD wideband codec: G.722 HD Codec, HD speakerphone, HD handset, HD headset
Full-duplex speakerphone with AEC
G.711u/a-law, G.723.1, G.726, G.729A/B
DTMF (In-Band, RFC2833, SIP Info)
Acoustic Echo Cancelation (AEC)
Acoustic Gain Control (AGC)
Voice Activity Detection (VAD)
Comfort Noise insertion
Transport Layer Security (TLS)
SRTP (RFC3711), SIPS
VLAN QoS (802.1p/q)
2 VoIP Accounts
Menu-driven user interface, XML Idle Screen, Theme, Screen Sleep
Call hold, Call waiting, Call forward, Call return, Redial, Call transfer
Caller ID display, Call history, Phonebook (1000 files), Black list, XML/LDAP phonebook
DND, Auto-answer, 3-Way Conference
Mute, Speed dial, SMS, Voicemail, Message Waiting Indication (MWI) LED
BLA/BLF, programmable soft keys
Hot-desking, Tone scheme, Volume control, Ring tone selection/Import/Delete
Interoperability with most of IP platforms (IPBX, Centrex SIP, etc.)
TCP, UDP, ICMP, RARP, ARP, DNS, NTP, SNTP, STUN, UPnP, SNMP
Layer 2(802.1Q, 802.1P) QoS
Layer 3 (ToS, DiffServ, MPLS) QoS
